Stationary Concrete Pump With 1600Mm Stroke 150m Vertical Conveying Distance
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | KEDA / POTENCY |
| Certification: | ISO9001:2015 |
| Model Number: | HBT50.13.129RS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 unit in 1*40'HQ |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 180 units per year |
|
Detail Information |
|||
| Model: | HBT50.13.129RS | Max. Theoretical Pressure: | 13 MPa |
|---|---|---|---|
| Pumping Cylinder Stroke: | 1600 Mm | Max. Vertical Conveying Distance: | 150 M |
| Application: | Concrete Pump | Power Type: | Diesel |
| Hopper Capacity: | 0.7 M3 | Overall Dimension: | 6400*2160*2100 |
| Highlight: | 1600Mm Stroke Concrete Pump,Concrete Pump 150m |
||
Product Description
Innovative and Professional Grade Concrete Pump HBT50.13.129RS for Superior Construction Work
HBT50.13.129RS Trailer Concrete Pump
Applications:
Introducing the KEDA / POTENCY Concrete Pump HBT50.13.129S, a high-quality cement pumping apparatus that is perfect for all your construction needs. Made in CHINA and certified with ISO9001:2015, this product is guaranteed to exceed your expectations in terms of quality, efficiency, and performance. With a minimum order quantity of 1 unit, the price is negotiable and payment can be made through T/T or L/C.
Construction sites: Drag type concrete pumps are widely used in concrete transportation, grouting, and spraying on construction sites, with the advantages of high efficiency, speed, and convenience, which can help workers complete a large amount of concrete work in a short time.
Underground engineering: In underground engineering such as tunnels and basements, due to the small space and high construction difficulty, trailer concrete pumps can solve the problem of concrete transportation caused by factors such as terrain and landforms.
High rise buildings: In the construction of high-rise buildings, trailer concrete pumps can greatly improve construction speed and efficiency, avoiding the high cost and low efficiency of traditional manual transportation methods.
Infrastructure: In infrastructure construction such as bridges and water conservancy projects, trailer concrete pumps can significantly improve construction efficiency and are suitable for tasks with large quantities and tight deadlines.
Other applications: The mixing and mopping pump can also be used for transporting green soil, grouting foundation piles, and transporting silt.
Features
1. Easy to move, strong and flexible
2. Stable and reliable, longer service life
3. Reliable and efficient, saving labor
4. Automatically add water
5. Fuel saving
6. Advanced dual hydraulic system
7. Uniform and stable spraying
8. Long life of mortar piston
9. Reduce pumping resistance
10. Cleaning is safer and faster
Specifications
| Model | HBT50.13.129RS | ||
| Item | |||
| Motor | WEICHAI | ||
| Power | KW | 129KW | |
| Rated speed | r/min | 2200 | |
| Max. theory concrete pumping pressure | Mpa | 7/13 | |
| Concrete cylinder diameter x stroke | mm | Φ200/1400 | |
| Valve | S Valve | ||
| Hopper capacity | m3 | 0.6 | |
| Filling height | mm | 1450 | |
| Hydraulic oil circuit form | Open circuit | ||
| Pumping oil relief valve set point | Mpa | 32 | |
| Distribution of oil relief valve set point | Mpa | 19 | |
| Mixing system oil pressure value | Mpa | 12 | |
| The highest stirring speed | r/min | 32 | |
| Allow the largest aggregate diameter | mm | Pebble 50, Gravel 40 | |
| The concrete pipe diameter | mm | Φ125/Φ150 | |
| Overall dimensions(L x W x H) | 6400*2160*2100 | 6600*2160*2700 | |
| Total weight | kg | 6200 | 6300 |
| Towing line speed | Km/h | ≤8 | |
