High Pressure Trailer Concrete Pump With Max Theoretical Pressure Of 18 MPa
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | KEDA / POTENCY |
| Certification: | ISO9001:2015 |
| Model Number: | HBT100.18.195RS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 Unit in 1*40'HQ |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 180 units per year |
|
Detail Information |
|||
| Hopper Capacity: | 0.7~0.8m3 | Max. Aggregate Size: | 50mm |
|---|---|---|---|
| Warranty: | 1 Year | Power Type: | Diesel & Electric |
| Hydraulic System Type: | Open Circuit | Application: | Stationary Concrete Pump, Trailer Pump |
| Max. Theoretical Pressure: | 18 MPa | Max. Theoretical Vertical Reach: | 180~220m |
| Highlight: | High Pressure Concrete Pump,Concrete Pump 18 MPa |
||
Product Description
HBT100.18.195RS High Pressure Trailer Concrete Pump with Hopper Capacity of 0.7-0.8m3 and Max. Theoretical Pressure of 18 MPa
Product Description:
Meet the KEDA/POTENCY Concrete Pump HBT100.18.195RS, a top-notch cement pumping equipment that can cater to all your construction requirements. This high-quality product is manufactured in CHINA and is ISO9001:2015 certified. You can expect nothing but the best in terms of quality, performance, and efficiency. The minimum order quantity is one unit, and the price is negotiable. You can make payment through T/T or L/C.
Drag type concrete pumps are widely employed in transporting, grouting, and spraying concrete on construction sites. These pumps are highly advantageous in terms of efficiency, speed, and convenience. They can help workers complete a substantial amount of concrete work in a short time.
In underground engineering, such as tunnels and basements, concrete pumps can solve concrete transportation problems due to factors like small spaces and high construction difficulty. Trailer concrete pumps are ideal for concrete transportation on such sites.
In the construction of high-rise buildings, trailer concrete pumps can significantly improve construction speed and efficiency, thus avoiding the high cost and low efficiency of traditional manual transportation methods.
Trailer concrete pumps are perfect for use in infrastructure construction, such as bridges and water conservancy projects. They can help enhance construction efficiency, especially for projects with large quantities and tight deadlines.
The mixing and mopping pump can be helpful in numerous other applications, ranging from transporting green soil and grouting foundation piles to moving silt.
Features:
Concrete trailer pumps are an efficient way to mix and pump concrete. They can greatly improve construction efficiency and shorten the construction period. In fact, their efficiency can reach 4-6 times that of traditional fixed mixers and concrete pumps, making them a cost-effective solution for any construction project.
The trailer pump is also known for its flexibility. It's usually equipped with wheels or trailer devices, making it easy to move between different construction sites. This adaptability allows for greater flexibility in construction operations, saving time and money.
One of the major advantages of trailer pumps is their ability to integrate mixing and pumping functions. This can greatly reduce equipment procurement and labor costs, while minimizing concrete waste. The high degree of automation also saves a lot of time and labor costs.
The mixing quality of concrete with a trailer pump is typically high with good mixing uniformity, which is essential for improving the quality of construction projects. The mixed concrete is more uniform and dense, with improved strength, tensile and flexural properties.
Safety is always a top priority in any construction project. The trailer pump comes with safety protection measures such as overload and leakage protection, ensuring a safe and reliable construction process.
Technical Parameters:
Product Specifications
| Parameters | Unit | HBT100.18.195RS |
|---|---|---|
| Max. theory concrete output | m³/h | 103/61 |
| Max. theory concrete pumping pressure | Mpa | 10/18 |
| Max. theory delivery distance (Vertical and horizontal) | m | 180/900 |
| Type | S valve | |
| Concrete cylinder diameter x stroke | mm | Ф200x1800 |
| Hopper capacity | m³ | 0.8 |
| Rated power of main motor | KW | 195 |
| Total weight | Kg | 6900 |
| Oil tank | L | 500 |
| Overall dimensions(L x W x H) | mm | 6800*2150*2830 |
Description
The HBT100.18.195RS is a s-valve concrete pump designed for construction use. It has the capability of delivering up to 103 cubic meters of concrete in an hour or 61 cubic meters of concrete in an hour . This is made possible by its maximum theory concrete output of 10 megapascals and 18 megapascals for pumping pressure.
In terms of delivery, the HBT100.18.195RS can pump concrete to a distance of up to 180 meters vertically and 900 meters horizontally . Its hopper capacity is 0.8 cubic meters and it has an oil tank that can hold up to 500 liters of oil.
The machine is powered by a 195 kW main motor and weighs 6900 kilograms . Its overall dimensions are 6800mm in length, 2150mm in width, and 2830mm in height .
Applications:
The HBT100.18.195RS Concrete Pump is designed and manufactured in CHINA, where it meets ISO9001:2015 standards. This certification ensures that the product is of the highest quality and meets all relevant safety standards.
The minimum order quantity for this product is 1 unit, and the price is negotiable. The packaging details include 1 unit in 1*40'HQ. The delivery time is 20 working days, and the payment terms include T/T and L/C. The supply ability is 180 units per year.
The max theoretical vertical reach of this concrete pump is 180~220m, and it has a hopper capacity of 0.7~0.8m3. The HBT100.18.195RS Concrete Pump can be used as both a stationary and trailer pump. It has a max theoretical pressure of 18 MPa, and its hydraulic system type is open circuit.
The HBT100.18.195RS Concrete Pump is ideal for a variety of application occasions and scenarios. For instance, it can be used for building foundations, bridges, tunnels, and high-rise buildings. It is also perfect for pouring concrete into hard-to-reach areas, such as upper floors of buildings or tight spaces. The HBT100.18.195RS Concrete Pump is also great for large construction projects where a static concrete pump is needed to deliver concrete to a specific location.
In summary, the HBT100.18.195RS Concrete Pump is a high-quality, versatile product that can be used in a wide variety of application occasions and scenarios. It is perfect for construction sites where the concrete needs to be delivered to a specific location. With its max theoretical vertical reach of 180~220m, hopper capacity of 0.7~0.8m3, and max theoretical pressure of 18 MPa, this concrete pump is sure to meet all your construction needs.
Packing and Shipping:
Product Packaging:
The Concrete Pump product will be carefully packaged in a sturdy cardboard box to ensure safe delivery. Inside the box, the pump will be securely wrapped in bubble wrap and protected with foam padding to prevent any damage during transportation.
Shipping:
Once the order is confirmed, we will process and ship the Concrete Pump within 3-5 business days. The shipping method will depend on the customer's location and will be chosen to ensure the fastest and most cost-effective delivery possible. Tracking information will be provided once the order has been shipped.
FAQ:
Q1: What is the brand name of this concrete pump?
A1: The brand name of this concrete pump is either KEDA or POTENCY.
Q2: What is the model number of this concrete pump?
A2: The model number of this concrete pump is HBT100.18.195RS.
Q3: Where is this concrete pump manufactured?
A3: This concrete pump is manufactured in China.
Q4: What certifications does this concrete pump have?
A4: This concrete pump is certified with ISO9001:2015.
Q5: What is the minimum order quantity for this concrete pump?
A5: The minimum order quantity for this concrete pump is 1 unit.
Q6: What is the price of this concrete pump?
A6: The price of this concrete pump is negotiable.
Q7: What are the packaging details for this concrete pump?
A7: The packaging details for this concrete pump is 1 unit in 1*40'HQ.
Q8: What is the delivery time for this concrete pump?
A8: The delivery time for this concrete pump is 20 working days.
Q9: What are the payment terms for this concrete pump?
A9: The payment terms for this concrete pump are T/T and L/C.
Q10: What is the supply ability of this concrete pump?
A10: The supply ability of this concrete pump is 180 units per year.
