Max. Theoretical Pressure 16MPa Concrete Filling Pump Max. Theoretical Vertical/Horizontal Reach of 500m
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | POTENCY |
| Certification: | ISO9001:2015 |
| Model Number: | HBMD200/1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 Unit in 1*40'HQ |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 120 units per year |
|
Detail Information |
|||
| Application: | Concrete Filling Pump | Oil Tank: | 1800L |
|---|---|---|---|
| Max. Theoretical Vertical/Horizontal Reach: | 500m | Max.Theoretical Horizontal Reach: | 10000m |
| Max.Theory Concrete Output: | 200m³/h | Rated Voltage: | 380/660/1140V |
| Max. Theoretical Pressure: | 16MPa | ||
| Highlight: | concrete filler pump,500m Concrete Filling Pump,16MPa Concrete Filling Pump |
||
Product Description
Max. Theoretical Vertical/Horizontal Reach of 500m and Max. Theoretical Pressure of 16MPa Concrete Filling Pump
Product Description:
The filling pump is primarily utilized for concrete filling in coal mine goafs and roadways, as well as for filling mined-out regions in ferrous metal, non-ferrous metal, gold mines, and other mines. It also serves for the long-distance and high-lift transportation of sludge from sewage treatment plants and the dredging of rivers and lakes.
Its broad range of applications includes pumping cake materials and various mixed materials like tailings, fly ash, coal gangue, construction waste, and fine stones. The filling pump has the ability to handle materials with a maximum concentration of up to 85%.
Features:
The conveying pressure reaches 16MPa, and it can pump concrete containing 3-5cm aggregates, with a wide range of slump adaptability (80-230mm). The hydraulic system adopts constant power control to prevent overload and improve the stability of continuous operation.
Integrated intelligent fault diagnosis system, real-time monitoring of operational data and early warning, reducing downtime. Key components such as S-tube valves and wear-resistant cylinders are equipped with high-pressure components or reinforced processes, which have a long service life and are easy to maintain.
Technical Parameters:
| Max. Theory Concrete Output | 200m³/h |
| Max. Theoretical Vertical/Horizontal Reach | 500m |
| Rated Voltage | 380/660/1140V |
| Max. Theoretical Pressure | 16MPa |
| Oil Tank | 1800L |
| Max.Theoretical Horizontal Reach | 10000m |
| Application | Concrete Filling Pump |
Applications:
Filling of goaf, recovery of coal pillars (achieving "pillar free mining"), and backfilling of coal gangue to reduce surface subsidence and pollution.
Temporary or permanent structural construction such as roadway spraying support, roadway reinforcement along the void, and rapid pouring of isolation walls.
Underground floor laying, wall backfilling, and concrete pouring in narrow spaces such as tunnels and water conservancy projects.
Support and Services:
Our Product Technical Support and Services for the Concrete Pump include:
- Troubleshooting assistance for any technical issues
- Repair and maintenance services to keep your Concrete Pump operating efficiently
- Training programs for operators to ensure safe and proper usage of the equipment
- Access to genuine spare parts and accessories for your Concrete Pump
- Regular updates on software and firmware upgrades to enhance performance
Packing and Shipping:
Product Packaging:
The concrete pump is securely packaged in a durable cardboard box with ample cushioning to prevent any damage during transit. The package includes the main pump unit, hoses, and accessories.
Shipping:
Our concrete pump is shipped using a reliable courier service to ensure safe and prompt delivery to your location. The package is carefully handled to prevent any mishaps during transportation.
