22.9m Stationary Height Concrete Placing Boom with 360° Slewing Angle and Cable Radio Remote Control
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | POTENTIAL / POTENCY |
| Certification: | ISO9001:2015 |
| Model Number: | HG32 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 Unit in 2*40'HQ |
| Delivery Time: | 60 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 120 units per year |
|
Detail Information |
|||
| Type Of Hydraulic Oil: | ESSO NUTO H46 Or H32 | Mode Of Operation: | Cable & Radio Remote Control |
|---|---|---|---|
| Stationary Height: | 22.9m | Pressure Of Hydraulic System: | 28Mpa |
| Application: | Concrete Placement | Slewing Angle: | 360° |
| Max Horizontal Reach: | 31.7m | Power Of Motor: | 15Kw |
| Highlight: | 360° Slewing Concrete Placing Boom,22.9m Concrete Placing Boom,Stationary Concrete Placing Boom |
||
Product Description
22.9m Stationary Height Concrete Placing Boom with 360° Slewing Angle and Cable Radio HG32 So Amazing
Product Description:
This concrete placing boom has a reach of 32 meters and features three arms, making it suitable for large-scale construction projects. It is designed for efficient concrete placement and is manufactured by KEDA Construction Machinery, a company with over 30 years of experience in construction machinery. The machine is certified by ISO9001:2000 and is marketed under the trademark "POTENTIAL"
Construction of High-Rise Buildings
When it comes to the construction of high-rise buildings, the HG32Bb placing boom offers unparalleled flexibility and precision in concrete placement. Its 10m column length and 31.7m placing radius make it an ideal choice for hard-to-reach areas such as upper floors and tight corners. Additionally, the boom's four sections further increase its flexibility and precision, making it a top choice for high-rise construction projects.
Concrete Spreader Systems
If you're in the market for a concrete spreader system for your construction site, the HG32Bb is an ideal choice. It is designed to transport concrete easily and efficiently from a central mixing station to the construction site, making it a versatile and reliable solution for all your concrete placement needs. Whether used as a standalone product or as part of a larger conveyor system, the HG32Bb delivers excellent results.
Cost-Effective and Available in Bulk
Construction companies of all sizes can benefit from the HG32Bb placing boom. With a minimum order quantity of just one unit and a negotiable price, it is a cost-effective choice for any construction project. Moreover, it has a supply ability of up to 120 units per year, ensuring quick access to the equipment you need.
The HG32Bb is an ideal choice for concrete placement in high-rise buildings, infrastructure projects, and concrete spreader systems.
Its features and specifications, such as a 10m column length, 31.7m placing radius, and four sections, offer unparalleled flexibility and precision in concrete placement.
It is designed to withstand the high demands of large construction projects, with a hydraulic system pressure of 28MPa and reliable seaworthy packaging.
The HG32Bb is available in bulk, with a minimum order quantity of just one unit and a supply ability of up to 120 units per year.
Features:
-
Reach: Ranges 32 meters, catering to different project sizes.
-
Design: Folding or stationary designs for easy assembly and flexibility.
-
Control: Proportional radio remote control for precise operation.
-
Stability: Double-supporting legs and high-quality rotary bearings for enhanced stability.
-
Certification: Many models are ISO9001 certified, ensuring quality and reliability
Technical Parameters:
| Power of Motor | 15Kw |
| Pressure of Hydraulic System | 28Mpa |
| Stationary Height | 22.9m |
| Application | Concrete Placement |
| Type of Hydraulic Oil | ESSO NUTO H46 Or H32 |
| Slewing Angle | 360° |
| Max Horizontal Reach | 31.7m |
| Mode of Operation | Cable & Radio Remote Control |
Applications:
Model: HG32Bb
Delivery pipe dimension (outside diameter × thickness) (mm × mm): Φ134×4
Delivery hose dimension (inside diameter × length) (″×mm): 5″×3000
Radius of placing boom (m): 31.7
(to the joint between the end of the boom and Swivel table) (m): 22.9
Four hydraulic foldable arms:
- 1st section: 9.55m
- 2nd section: 8.27m
- 3rd section: 7.11m
- 4th section: 7.07m
Boom articulation:
- 1st section: -4.2°～＋82.5°
- 2nd section: 0°～180°
- 3rd section: 0°～180°
- 4th section: 0°～180°
Slewing range (°): 360
Power of motor (kW): 15
Pressure of hydraulic system (MPa): 28
Type of hydraulic oil:
Interval of climbing frame (m):
- Climbing: 3.0～4.2
- Placing concrete: 6.0～8.4
- Resting
Mode of operation:
- cable remote control
- radio remote control
Power: 380V/50Hz
Wind speed:
- Placing concrete: ≤60 km/h
- Climbing: ≤28 km/h
Working temperature: -20℃～48℃
Counterweight: W/O
Customization:
Product Customization Services for Climbing Concrete Placing Boom
Brand Name: POTENTIAL / POTENCY
Model Number: HG32
Place of Origin: CHINA
Certification: ISO9001:2015
Minimum Order Quantity: 1 Unit
Price: Negotiable
Packaging Details: 1 Unit in 2*40'HQ
Delivery Time: 60 working days
Payment Terms: T/T, L/C
Supply Ability: 120 units per year
Type of Hydraulic Oil: ESSO NUTO H46 Or H32
Stationary Height: 22.9m
Pressure of Hydraulic System: 28Mpa
Max Horizontal Reach: 31.7m
Power of Motor: 15Kw
Product Keywords: Climbing Concrete Placing Boom, Concrete Placing Boom, Concrete Distributor Boom
FAQ:
Q: What is the brand name of the Concrete Placing Boom?
A: The brand name is POTENTIAL / POTENCY.
Q: What is the model number of the Concrete Placing Boom?
A: The model number is HG32.
Q: Where is the Concrete Placing Boom manufactured?
A: The Concrete Placing Boom is manufactured in CHINA.
Q: What certification does the Concrete Placing Boom have?
A: The Concrete Placing Boom is certified with ISO9001:2015.
Q: What is the minimum order quantity for the Concrete Placing Boom?
A: The minimum order quantity is 1 Unit.
